ASRock B460M-HDV m-ATX Motherboard
Original price was: ₹15,000.₹6,949Current price is: ₹6,949.
(incl. all taxes)
- Micro ATX Form Factor
- Supports 10th Gen Intel Core Processors (Socket 1200)
- Supports D-Sub, DVI-D, and HDMI Â Tripple Monitors
- Intel B460 Chipset Support
- Supports Surge Protection
ABOUT ASRock B460M-HDV m-ATX Motherboard
Conventional PC system processors can only access a fraction of the graphics memory and limit the performance of the system. With Clever Access Memory, data channels are expanded to increase GPU memory capacity, eliminate clutter, and increase performance. Intel LAN offers optimal throughput performance, low CPU usage, and enhanced stability, and can provide users with the ultimate network experience.
The PCIe Gen3 x4 Ultra M.2 interface pushes data transfer speeds up to 32Gb / s and is compatible with ASRock’s U.2 Kit for installing the world’s fastest U.2 PCIe Gen3 x4 SSD.
In addition to the onboard LAN port, users can also choose the 802.11ac wireless connection via the M.2 (Key E) slot. Intel Optane supports memory technology and Intel Optane storage technology that redefines a new standard of high efficiency and responsiveness. Complete with three types of most-used connectors.
FEATURES:
Smart Access Memory –
Conventional PC system processors can only access a fraction of the graphics memory and limit system performance. With Clever Access Memory, the data channel is expanded to exploit the full potential of GPU memory, eliminating bottlenecks and increasing performance.
Intel LAN –
Intel LAN provides the best throughput performance, lower CPU usage, and improved stability and is able to provide users with the ultimate network experience!
Ultra M.2 32 Gb/s (PCIe Gen3 x4) –
The PCIe Gen3 x4 Ultra M.2 interface makes data transfer speeds up to 32Gb/s, and is compatible with ASRock’s U.2 kit for installing some of the world’s quickest U.2 PCIe Gen3 x4 SSDs.
M.2 (Key E) for WiFi –
In addition to the onboard LAN port, users can also opt for 802.11ac wireless connectivity via the M.2 (key E) slot.
NOTE: Wi-Fi module not included
Intel Optane Memory is ready –Â
Supports Intel Optane Memory Technology and Intel Optane Storage Technology that redefine a new average of high performance and responsiveness.
3 Graphics Outputs –
Complete with all three types of most used connectors! Packed with a D-Sub + DVI-D + HDMI combo. Also, the HDMI port supports 4K resolution.
Water Pump Header –
It not only supports a standard CPU fan header, but also a water pump! This header provides a maximum of 2A power to support the most popular water pumps. Users can adjust the water pump voltage to get high cooling performance with low noise.
TECHNICAL SPECIFICATIONS: ASRock B460M-HDV m-ATX Motherboard
| Â Model | Â B460M-HDV |
| Â CPU | Â – Supports 10th Gen Intel Core Processors (Socket 1200) – Digi Power design – 7 Power Phase design – Supports Intel Turbo Boost Max 3.0 Technology |
| Â Chipset | Â – Intel B460 |
| Â Form Factor | Â – Micro ATX Form Factor: 8.9-in x 7.4-in, 22.6 cm x 18.8 cm – Solid Capacitor design |
|  Memory |  – Dual-Channel DDR4 Memory Technology – 2 x DDR4 DIMM Slots – Supports DDR4 2933 / 2800 / 2666 / 2400 / 2133 non-ECC, un-buffered memory* – Supports ECC UDIMM memory modules (operate in non-ECC mode) – Max. the capacity of system memory: 64GB** – Supports Intel Extreme Memory Profile (XMP) 2.0 – 15μ Gold Contact in DIMM Slots*Please refer to the Memory Support List on ASRock’s website for more information. Core (i9/i7) supports DDR4 up to 2933; Core (i5/i3), Pentium, and Celeron support DDR4 up to 2666.**Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation. |
| Â BIOS | Â – 128Mb AMI UEFI Legal BIOS with multilingual GUI support – ACPI 6.0 Compliant wake-up events – SMBIOS 2.7 Support – CPU Core/Cache, GT, DRAM, VPPM, PCH 1.05V, VCCST, VCCSA Voltage Multi-adjustment |
| Â Graphics | Â – Hardware Accelerated Codecs: AVC/H.264, HEVC/H.265 8bit, HEVC/H.265 10bit, VP8, VP9 8bit, VP9 10bit, MPEG 2, MJPEG, VC-1** – Graphics, Media & Compute: Microsoft DirectX 12, OpenGL 4.5, Intel Built-In Visuals, Intel Quick Sync Video, Hybrid / Switchable Graphics, OpenCL 2.1 – Display & Content Security: Rec. 2020 (Wide Color Gamut), Microsoft PlayReady 3.0, Intel SGX Content Protection, UHD Blu-ray Disc – Three graphics output options: D-Sub, DVI-D, and HDMI – Supports Triple Monitor – Supports HDMI 1.4 with max. resolution up to 4K x 2K (4096×2160) 30Hz – Supports DVI-D with max. resolution up to 1920×1200Â 60Hz – Supports D-Sub with max. resolution up to 1920×1200Â 60Hz – Supports Auto Lip Sync, Deep Color (12bpc), xvYCC, and HBR (High Bit Rate Audio) with HDMI 1.4 Port (Compliant HDMI monitor is required) – Supports HDCP 2.3 with DVI-D and HDMI 1.4 Ports – Supports 4K Ultra HD (UHD) playback with HDMI 1.4 Port*Intel UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated.**VP9 10bit and VC-1 are for decode only. VP8 and VP9 encode are not supported by Windows OS. |
| Â Audio | Â – 7.1 CH HD Audio (Realtek ALC887 Audio Codec) – Supports Surge Protection |
| Â LAN | Â – Gigabit LAN 10/100/1000 Mb/s – Giga PHY Intel I219V – Supports Wake-On-LAN – Supports Lightning/ESD Protection – Supports Energy Efficient Ethernet 802.3az – Supports PXE |
| Â Slots | Â – 1 x PCI Express 3.0 x16 Slot* – 2 x PCI Express 3.0 x1 Slots – 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module*Supports NVMe SSD as boot disks |
| Â Storage | Â – 4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology 17), NCQ, AHCI and Hot Plug – 1 x Ultra M.2 Socket (M2_1), supports M Key type 2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)**PCIe RAID function is not supported Supports Intel Optane Technology Supports NVMe SSD as boot disks Supports ASRock U.2 Kit |
| Â Connector | Â – 1 x Print Port Header – 1 x COM Port Header – 1 x SPI TPM Header – 1 x Chassis Intrusion and Speaker Header – 1 x CPU Fan Connector (4-pin)* – 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)** – 2 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)*** – 1 x 24 pin ATX Power Connector – 1 x 8 pin 12V Power Connector – 1 x Front Panel Audio Connector – 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection) – 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports) (Supports ESD Protection)*The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.**The CPU/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power.***The Chassis/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power. CPU FAN2/WP, CHA FAN1/WP, and CHAFAN2/WP can auto-detect if a 3-pin or 4-pin fan is in use. |
| Â Rear Panel I/O | Â – 1 x Antenna Bracket – 1 x PS/2 Mouse/Keyboard Port – 1 x D-Sub port – 1 x DVI-D port – 1 x HDMI Port – 2 x USB 2.0 Ports (Supports ESD Protection) – 4 x USB 3.2 Gen1 Ports (Supports ESD Protection) – 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) – HD Audio Jacks: Line in / Front Speaker / Microphone |
| Â Software and UEFI | Â Software – ASRock Motherboard Utility (A-Tuning) – ASRock XFast LAN UEFI – ASRock EZ Mode – ASRock Full HD UEFI – ASRock My Favorites in UEFI – ASRock Instant Flash – ASRock Internet Flash – ASRock Easy RAID Installer*These utilities can be downloaded from ASRock Live Update & APP Shop. |
| Â Support CD | Â – Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser, and Toolbar |
| Â Accessories | Â – Quick Installation Guide, Support CD, I/O Shield – 2 x SATA Data Cables – 2 x Screws for M.2 Sockets |
| Â Hardware Monitor | Â – Temperature Sensing: CPU, CPU/Water Pump, Chassis/Water Pump Fans – Fan Tachometer: CPU, CPU/Water Pump, Chassis/Water Pump Fans – Quiet Fan (Auto adjust the chassis fan speed by CPU temperature): CPU, CPU/Water Pump, Chassis/Water Pump Fans – Fan Multi-Speed Control: CPU, CPU/Water Pump, Chassis/Water Pump Fans – CASE OPEN detection – Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM, VPPM, PCH, VCCSA, VCCST |
| Â OS | Â – Microsoft Windows 10 64-bit / 11 64-bit |
| Â Certifications | Â – FCC, CE – ERP/EuP ready (ErP/EuP ready power supply is required) |
| Â Unique Feature | Â ASRock Super Alloy – Premium 50A Power Choke – Sapphire Black PCB – High-Density Glass Fabric PCB ASRock Ultra M.2 (PCIe Gen3 x4 & SATA3) ASRock Full Spike Protection (for all USB, Audio, LAN Ports) ASRock Live Update & APP Shop |
| Â Product Dimension | Â 27.69 x 21.59 x 6.35 cm; 809 Grams |
|  Weight | ‎ 809 g (Approx) |
